UR's seventh-generation cobot platform, launched at IMTS, with three new g-Series arms and an AI-ready tool flange that carries power, data and safety for cameras and sensors.
Key specs
| Models | UR10g-1750, UR17g-1300, UR18g-950 |
|---|---|
| Payload | 10 kg ext. (UR10g), 17.5 kg ext. (UR17g), 18 kg (UR18g) |
| Reach | 1750 / 1300 / 950 mm |
| Repeatability | ±0.08 mm (UR10g), ±0.05 mm (UR17g/UR18g) |
| Max TCP speed | up to 5 m/s |
| Degrees of freedom | 6 |
| Tool flange | 24/48 V power, 1 Gb Ethernet, M8 I/O at flange |
| IP rating | IP65 |
| Safety | PLd Cat 3 (ISO 13849-1) |
